ATD Lighting
| Availability: | |
|---|---|
Light Source
Main light source: 392*1W cold white LED
Auxiliary lighting: 784*0.5W RGB LED
Average life:> 20,000 hours
Control
Protocols: DMX, Art-net, SACN, voice control, Auto 1, Auto 2
Control Channels:8CH/11CH/13CH/24CH/30CH/47CH/68CH/74CH/97CH
Firmware Upgrade: Upgrade via DMX link
4 touch button control panel
Display: OLED display
Pan & Tilt
Tilt Movement: 185°
Automatic Pan/Tilt position correction
Resolution: 16 bit
Electrical and Connectors
Input Voltage: 100-240Vac; 50/60Hz
Power : 500W
Power In/Out: Waterproof power connector in
Data In/Out: 3-pin or 5-pin waterproof XLR
Other Effects
Outstanding strobe effect with variable speed
Smooth dimming 0-100% (4 user selectable dimming curves)
Outstanding color mixing
Combine Dot, Pixel and Strobe Lines in one
Work Environment
Max Ambient Temperature: 40°C
Mini Operating Temperature: -10°C
Protection Rating: IP65
Fixture Dimensions:
Size: 406*202*334mm
Weight: 10.5 kg
