Mini Blinder IP

Electrical and Connectors

• Input Voltage Range: AC100-240V; 50/60Hz

• Power: 245W

• Power In/Out:Waterproof power connector in/out

• Data In/Out: 3-pin or 5-pin waterproof XLR

LIGHT SOURCE

• Light source: 178*2W RGBLAC LEDs

• Total Lumen Output of Fixture: 12,700 lumens

• Color Temperature Output of Fixture:1800K-8500K

• Dimming frequency: 2,000Hz～23,000Hz

• Life Expectancy: 20,000 hours
  *Source manufacturer specification

Control

• 4 Touch Button Control Panel

• Display: OLED display

• Protocols: DMX512 /Auto / Manual

• DMX Protocol Modes: 12

• Control Channels:1CH / 2CH / 3CH /4CH/ 6CH / 7CH / 13CH / 21CH / RGB10CH / RGB15CH / CMY10CH / CMY15CH

Optical System

• Beam Angle : 65°（Optional：35°）

Other Effect

• Dimmer: Smooth dimming 0～100%

• Dimming curve : Linear / square / Anti-Square / S-Line

• Fans dissipate heat

Fixture Dimensions:

• Size: 210*150*275mm

• Weight: 3.47 kg

Protection Rating:

• IP65
