Electrical & Interface:
Input Voltage: 100 - 240V, 50/60 Hz
Light Source
Light source: 37x40W RGBW LED
Color Temperature: 6000K
life expectancy: 20000 hours
*It may vary depending on va
rious factors, such as the type of use and environment
Optical System:
Zoom Range: 11° - 52°
Lumen output: 16,100Lm
Control And Connections:
Personalities:
Control Channels: 21/22/35/36/111/148CH
Protocols: DMX , RDM，AUTO，Master and slave (optional)
l LCD Display
Connectors:
Signal in/ out: 3 / 5 pin waterproof XLR IN/ OUT，RJ45 IN(optional)
Power connector: waterproof Power Con True1 IN/OUT
Dynamic Effects:
Colors:
Built in macros with enhanced pixel control
Preset colors
Dedicated channel for color temperature setting
White CT Emulation 2500 8000K
Bi directional rotating front lenses
Pan & Tilt
Tilt Movement: 210°
Pan Movement: 540°
Automatic Pan/Tilt position correction
Resolution: 16 bit
Dimmer/Shutter:
l High resolution electronic dimmer 24 bit, 4 curves
l High speed electronic shutter and strobe:
l Slow strobe: 1 flash/sec
l Fast strobe: 25 flash/sec
Work Environment:
Max ambient temperature: 40°C
Max temperature of the external surface: 90°C
Protection rating：IP65
Size and Weight:
Size: 530*280*665mm
Net Weight: 31Kg
