Electrical & Interface:
Input voltage: 100-240V, 50/60 Hz
Power: 440W
Light source:
Light Source: 400 x 0.5W RGB LED + 200 x 1W White LED
LED life: 50.000 Hrs
* It may vary depending on various factors, such as the type of use and environment
Optical System:
Zoom range: RGB LED: 72° @50% / 115° @10%
White LED strobe: 120° of beam aperture
Lm output: 26,526 Lm
Control & Connections:
Control channels: 5 modes with 9 / 13 / 31 / 33 / 39CH
Pixel engine: 75CH
Strobe engine: 25CH
Protocols: DMX, Art-Net, sACN, RDM
Connections:
Locking 5 pin XLR IN/OUT
RJ45 IN/OUT
Power In/Out: Power Con True1 IN/OUT
Dynamic Effects:
Colors:
400 pcs 3-in-1 RGB LEDs split into 25 areas
200 pcs white LEDs split into 25 areas
White CT emulation 2800 – 8000K
RGB and strobe shape effect
Frost:
Black filter (Optional)
White filter 20° (Optional)
White filter 30° (Optional)
HARDWARE & SOFTWARE:
Long life self-charging battery
Display graphic LCD backlit B/W display
Firmware upgrade via DMX
DMX monitoring
Remote access through RDM
THERMAL SPECIFICATION:
MAX Ambient: 45°C (113°F)
Min Ambient: -20°C (-4°F)
MAX temp. of the ext. surface: 90°C (194°F)
Protection Rating: IP20
Sizes & Weight:
Dimensions: 990 x 199 x 76 mm
Net Weight: 5.7 Kg
