ATD Lighting
| Availability: | |
|---|---|
Electrical & Interface
Input Voltage: AC 100-240V, 50/60Hz
Power: 1500W
Light Source
Light Source:
240×12W RGBW LEDs
30×10W white LEDs
White Light Color Temperature: 6300K
Beam Angle:
Color LEDs: 102°
White LEDs: 3.5°
LED Lifespan: ≥20,000 hours
Control
Control Protocol: Standard 3-pin DMX512
Channel Modes: 10/17/24/21/26/36/41/61/150 channels
Work Environmental
Maximum Ambient Temperature: 40°C
Minimum Operating Temperature: 0°C
Maximum Surface Temperature: 65°C
Protection Rating
IP20
Fixture Specifications
Dimensions (L×W×H): 483×224×212mm
Net Weight: 14kg
