Control
Control Modes: DMX-512, Manual, Timer, Wireless Remote (Optional)
Channel Modes: 2CH (Fog Output, Airflow Output)
Electrical & Interface
Input Voltage: AC 100-240V, 50/60Hz
Power Consumption: 1500W
Speed-Adjustable Fan: External fan (Max. 500W)
Work Environment
Ambient Temperature: 0°C–45°C
Performance Specifications
Max. Fog Output: Adjustable, up to ~200m³/min
Fog Fluid Consumption: 180ml/hour (at 100% output)
Consumables: High-quality water-based fog fluid + CO₂/N₂ gas
Gas Working Pressure: 1.5–2.5 bar
Gas Consumption: 0.6 kg/hour (at 100% output)
Fixture Specifications
Dimensions (L×W×H): 620×220×336mm
Net Weight: 15kg
Fluid Tank Capacity: 2 liters
Control
Control Modes: DMX-512, Manual, Timer, Wireless Remote (Optional)
Channel Modes: 2CH (Fog Output, Airflow Output)
Electrical & Interface
Input Voltage: AC 100-240V, 50/60Hz
Power Consumption: 1500W
Speed-Adjustable Fan: External fan (Max. 500W)
Work Environment
Ambient Temperature: 0°C–45°C
Performance Specifications
Max. Fog Output: Adjustable, up to ~200m³/min
Fog Fluid Consumption: 180ml/hour (at 100% output)
Consumables: High-quality water-based fog fluid + CO₂/N₂ gas
Gas Working Pressure: 1.5–2.5 bar
Gas Consumption: 0.6 kg/hour (at 100% output)
Fixture Specifications
Dimensions (L×W×H): 620×220×336mm
Net Weight: 15kg
Fluid Tank Capacity: 2 liters
