ATD Lighting
| Availability: | |
|---|---|
Light Source:
Laser Power: 2W total (Red: 500mW / Green: 500mW / Blue: 1000mW)
Color Temperature (CCT): Cool White (5500K)
Color Modes: RGB Full Color / Pure White / Color Mixing
Laser Class: Class IIIB (Note: Requires proper classification verification)
Optical System:
Projection Distance: ≥10 meters
Scanning System: High-speed galvanometer scanner (180° scanning angle)
Control:
Control Modes: Master/Slave, Auto, DMX512, Sound-Active
Signal Response Time: <0.5 second (customizable)
Axis Control: (Not specified in original text)
Electrical Specifications:
Input Voltage: AC 100-240V, 50/60Hz
Work Environment:
Ambient Temperature Range: -20℃ to +35℃
IP Rating: IP20
Fixture Specifications:
Dimensions (W×H×D): 210×145×110 mm
Net Weight: 2.7 kg
